Infrastructure Systems: Smart energy systems

Scholar: Sean Passmore

Home Institution: Valdosta State University

PROJECT

Fault detection remains a key problem for reducing the operation and maintenance costs of marine hydrokinetic (MHK) turbines. With this in mind, a deep bidirectional long short-term memory (Bi-LSTM) network for rapid detection of MHK turbine faults is presented. The effectiveness of the proposed scheme is validated using simulated time-series sensor data from the Fatigue, Aerodynamics, Structures, and Turbulence (FAST) turbine simulation platform. Four-factor analysis of variance is performed along with post-hoc testing at the 95\% confidence level to establish the model's capabilities. Operating conditions, input length, training pitch, and generalization pitch are used as factors in this experiment. The models are trained on data consisting of 500 baseline and 500 faulty examples of a single blade pitch imbalance. To evaluate generalization performance, the models are applied, without fine-tuning, on the remaining levels of fault. Over 70\% mean generalization accuracy in all cases, with an optimal accuracy over 95\% given 1 second lengths of data, is observed. No significant difference is found due to varying operating conditions, indicating a robust model. Training on lower levels of fault demonstrated greater generalization capability. To the best of our knowledge, this is the first time that Bi-LSTM has been applied as a building block for a MHK turbine fault detection model.

Click here for the slide presentation. Click here to watch the video presentation.
